INTRODUCTION:

Incoloy is a series of nickel based alloy products composed of nickel, iron, and other alloy elements such as chromium, molybdenum, copper, etc. These products have excellent high-temperature resistance, corrosion resistance, and antioxidant properties, suitable for various industrial fields. Below is an introduction to several common Incoloy products:
Incoloy 800/800H/800HT: This series of products is an alloy containing a high proportion of nickel and iron, with good heat resistance and oxidation resistance. The Incoloy 800 series can maintain stability at high temperatures and has excellent thermal cycling resistance. They are widely used in equipment such as high-temperature stoves, heaters, pipelines, and storage tanks.
Incoloy 825: Incoloy 825 is a corrosion-resistant alloy that contains elements such as nickel, iron, and chromium, as well as copper and molybdenum. It has excellent corrosion resistance, especially good resistance to strong acids and seawater environments. Incoloy 825 is commonly used in chemical equipment, pipelines and valves in marine environments, etc.
Incoloy 625: Incoloy 625 is a high-strength, corrosion-resistant alloy that contains elements such as nickel and chromium, as well as niobium and molybdenum. It has excellent corrosion resistance and high-temperature strength, especially suitable for corrosive environments in marine and chemical industries. Incoloy 625 is commonly used in oil well pipelines, chemical equipment, and marine installations in the oil and gas industry.

Incoloy 901: Incoloy 901 is a high-strength alloy that contains elements such as nickel and iron, as well as titanium and aluminum. It has excellent high-temperature strength and antioxidant performance, suitable for applications in high-temperature environments. Incoloy 901 is commonly used in high-temperature component manufacturing in fields such as aerospace, automotive, and power generation.


elementNiCrMoNbFeAl
smallest5820 3.15--
maximum-23104.1550.4


elementCMnSiCuPS
smallest------
maximum0.10.50.50.50.0150.015


productASTM
RodB 446
Plate, sheet and stripB 443, B 906
Seamless pipes and fittingsB 444, B 829
welded pipeB 705, B 775
Welded pipe fittingsB 704, B 751
Welded connectionsB 366
Forged billets and barsB 472
ForgingsB564


Alloys and Conditions625
Tensile strength Rm N/mm2760
Yield strength RPO.2N/mm2345
Elongation A5 %30
Brinell hardness HB220
